Leje en Leit- u. Zugspindeldrehmaschine COLCHESTER

Publiceret: 1mån. 19d.

Publiceret: 1mån. 19d.

Referencenummer

27446

Lokation

Germany, Flachstr. 11, 65197 Wiesbaden, Germany

Mere information

Beschreibung

Spitzenhöhe: 195 mm

Spitzenweite: 1250 mm

gr. Umlauf-Ø über Bett/Supportschlitten: 400/265 mm

Spindelaufnahme/-bohrung: Camlock D1-6"/54 mm

Aufnahmekegel der Reitstockpinole: MK 5

Spindeldrehzahlen in 3 Gruppen stufenlos regelbar: 0 - 2500 Upm

Vorschübe längs: 0,018 - 1,2 mm

Vorschübe plan: 1/2 der Längsvorschübe

51 metrische Gewindesteigungen: 0,2 - 14 mm

56 Zollgewinde: 2 - 56 Gg/"

20 Modulgewinde: 0,2 - 3,5 Modul

20 Diametral-Pitch-Gewinde: 8 - 56 DP

elektr. Anschluß: 400 V, 7,5 kW

Gewicht: 1500 kg

Platzbedarf: 2500 x 1300 x 1300 mm

Alle anzeigen
